Description
This automatic spout pouch filling machine is applicable for liquid raw materials measuring, spout pouch filling and capping. It is a high-quality liquid pre-made bags filling machine for spout pouch packaging specifically, with multi-head rotary filling nozzle (controlled by servo injection) to enhance both filling accuracy and filling efficiency. Different type of measuring pump is available according to the viscosity, thickness and fluidity of liquid product; user can make slight change on filling weight through measure head. The spout pouch holding rack can be adjusted to fit for different size of spout pouch, giving user the most flexibility in manufacturing if package size is changed. It is widely used in food&beverage, pharmaceutical, nutraceutical and chemical industries.
The machine features with full automatic operation, high capacity production, highly stable performance, accurate measuring, low malfunction rate, and long life-span. It is applicable for the packaging of liquid products, such as beverages, instant drinks, juice, jelly, puree, coffee liquid, sauce, jam, and other fluid products, shampoo, lotion, cream, gel etc. The entire machine is under advanced PLC system control. With a user interface for easy adjustments and monitoring, the automatic spout pouch filling machine enhances efficient and continuous production, reduces labor and improves outcome consistency.
Working Flow:
- Liquid material mixing (if need) and feeding
- Liquid material measuring
- Spout pouch fetching
- Manufacturing date printing
- Filling into spout pouch
- Lid feeding
- Screw capping
- Finished product conveying
Package and Application:
Video:
Technical Parameters:
| Machine Name | Automatic Spout Pouch Filling Machine |
| Machine Model | LY-SP800 |
| Capacity | 50-150pcs/min |
| Bag Dimension | Width: 100-200mm (3.93-7.87inches) Length: 100-300mm (3.93-11.81inches) |
| Measuring Range | 60-300ml |
| Measure Head | Pump |
| Control System | PLC |
Services:
- Initial needs analysis, solution proposal according to needs
- Technical assessment and prototype verification
- Manufacturing, testing, debugging, pre-setting, shipping and delivering
- 24/7 technical support and life-time after sales service
- Packaging supplies testing and support
- Upgrades and modification support
