Description
This automatic powder bottle filling line is applicable for powder products measuring, filling into containers, capping and labeling. It consists of automatic products feeder, multi-nozzle filling head, container and lid feeding elevator, foil induction sealing system, scoop/desiccant insert device, capping and labeling device. The precisely machined screw system is applicable for any fine powdery raw materials measuring, user can make slight change on filling weight through system setting change. The package size is customizable according to demand. Different levels of automation can be achieved according to needs. It is widely used in food&beverage, pharmaceutical and nutraceutical industries.
The machine line is featuring with full automatic operation, high capacity production, highly stable performance, accurate measuring, low malfunction rate, and long life-span. Applicable for bottles filling of powder products, such as food powder, spice powder, drink powder, supplement powder, nutraceutical powder, chemical powder etc. The entire line is under advanced PLC system control. With a user interface for easy adjustments and monitoring, the automatic powder bottle filling line enhances efficient and continuous production, reduces labor and improves outcome consistency.
Working Flow:
- Powdery material feeding
- Powdery material measuring
- Container and lid feeding
- Filling into containers
- Scoop/desiccant inserting (if needed)
- Induction foil sealing
- Lid capping
- Container labeling
- Manufacturing date printing
- Weight checking (if needed)
- Finished product conveying
Package and Application:
Video:
Technical Parameters:
| Machine Name | Automatic Powder Bottle Filling Line |
| Machine Model | LY-PL1000 |
| Capacity | 10-50pcs |
| Package Dimension | Bottle mouth: Φ35-130mm Height: 25-220mm |
| Measuring Range | 10-3000g |
| Measure Head | Screw |
| Control System | PLC |
Services:
- Initial needs analysis, solution proposal according to needs
- Technical assessment and prototype verification
- Manufacturing, testing, debugging, pre-setting, shipping and delivering
- 24/7 technical support and life-time after sales service
- Packaging supplies testing and support
- Upgrades and modification support
