Description
This automatic horizontal wrapping machine is applicable for larger granular products wrap packaging. The model is able to make individual package of granular products in different shape and size. Manual products feeding and placement is required for products that cannot be sorted or measured by general measure head. The package sealing temperature can be changed to accommodate to packing film in different material and thickness. Package size is customizable according to requirements, the machine can automatically detect the length of product and determine the package length itself, without human intervention. Machine will activate its auto stop feature once it detects shortage of packaging supplies or products. It is widely used in food, daily supplies, and nutraceutical industries.
The model features with full automatic operation, high compatibility, high capacity production, highly stable performance, accurate measuring, low malfunction rate, and long life-span. It is applicable for the packaging of tablet products, such as breads, cakes, sandwiches, burgers, fruits, vegetables, chocolate bar, soap bar, cutlery, parts etc. The entire machine is under advanced PLC system control. With a user interface for easy adjustments and monitoring, the automatic horizontal wrapping machine enhances efficient and continuous production, reduces labor and improves outcome consistency.
Working Flow:
- Manual products feeding and placement
- Automatic inline products conveying
- Packing film feeding
- Manufacturing date printing
- Package forming
- Nitrogen flushing (if needed)
- Package sealing
- Package cutting off
- Finished product conveying
Package and Application:
Video:
Technical Parameters:
| Machine Name | Automatic Horinzontal Wrapping Machine |
| Machine Model | LY-HF250 |
| Capacity | 20-230pcs/min |
| Bag Dimension | Width: 30-280mm (1.18-11.02inches) Length: / Height: 40-110mm (1.57-4.33inches) |
| Control System | PLC |
Services:
- Initial needs analysis, solution proposal according to needs
- Technical assessment and prototype verification
- Manufacturing, testing, debugging, pre-setting, shipping and delivering
- 24/7 technical support and life-time after sales service
- Packaging supplies testing and support
- Upgrades and modification support
