Description
This automatic granules bottle filling line is applicable for granular products weighing, filling into containers, capping and labeling. It consists of automatic products feeder, multi-head electronic scale weighing system, container and lid feeding elevator, desiccant insert device, foil induction sealing system, capping and labeling device. The multi-head electronic scale weighing system is able to weigh different granular products accurately, with a tolerance rate as low as 0.2%; user can make change on filling weight through system, without the need of parts change. The package size is customizable according to demand. Different levels of automation can be achieved according to needs. It is widely used in food&beverage, pharmaceutical and nutraceutical industries.
The machine line is featuring with full automatic operation, high capacity production, highly stable performance, accurate measuring, low malfunction rate, and long life-span. Applicable for bottles filling of granular products, such as bean, nut, spice, grain, seed, candy, herb, snacks etc. The entire line is under advanced PLC system control. With a user interface for easy adjustments and monitoring, the automatic granules bottle filling line enhances efficient and continuous production, reduces labor and improves outcome consistency.
Working Flow:
- Granular material feeding
- Granular material weighing
- Container and lid feeding
- Filling into container
- Desiccant inserting
- Induction foil sealing
- Lid capping
- Container labeling
- Manufacturing date printing
- Weight checking (if needed)
- Finished product conveying
Package and Application:
Video:
Technical Parameters:
| Machine Name | Automatic Granules Bottle Filling Line |
| Machine Model | LY-GL1000 |
| Capacity | 20-60pcs/min |
| Package Dimension | Bottle mouth: Φ25-180MM |
| Measuring Range | 200-2500g (0.44-5.51lb) |
| Measure Head | Multi-head Electronic Scale |
| Control System | PLC |
Services:
- Initial needs analysis, solution proposal according to needs
- Technical assessment and prototype verification
- Manufacturing, testing, debugging, pre-setting, shipping and delivering
- 24/7 technical support and life-time after sales service
- Packaging supplies testing and support
- Upgrades and modification support
